PRODUCT FEATURES
- Positive Weston-style brake will hold the load in any position.
- Compact, lightweight and rugged construction.
- Mechanical components are enclosed for protection and safety.
- Powder-coated.
- Rope to drum fixing clamp provided.
- Heat-treated gears.
- Strong removable handles.
- High precision construction minimises gear noise.
- AS1418.2 Compliance applies when correctly fitted with approved wire rope and fittings.
| Model No. Bare | BHW1200 | ||
| Rated Capacity - Pulling | 545kg/8.04kN | ||
| Rated Capacity - Hoisting | 270kg | ||
| Type of Brake | Double Paw | ||
| Max Hand Force Req. | 22kg | ||
| Gear Ratio | 5:1 | ||
| Hub Diamater | 70mm | ||
| Handle Length | 320mm | ||
| Unit Weight - Bare | 8kg | ||
| Wire Rope Diameter | 7mm | ||
| Wire Rope Construction | 6x19 FC RHL | ||
| Grade of Wire Rope | 1770 | ||
| Wire Rope Finish | Hot Dipped Galvanised | ||
| Wire Rope Storage Capacity | 26m | ||
